Engineered for best value and worry-free storage, Trojan Solar AGM maintenance-free batteries can be counted on day in and day out as a reliable power source for a wide range of off-grid and unreliable grid applications, including:
| • Remote micro-grids | • Solar home systems |
| • Solar street signs/lights | • Residential & commercial backup |
| • Off-grid cabins/tiny house | • Telecom |
| • Oil & gas |
Trojan’s proven quality and reliability is the result of our extensive engineering expertise in deep-cycle battery design. Our Solar AGM batteries feature:
- Ruggedized polypropylene case
- Optimized paste formula for deep-cycle operation
- Reinforced cell compression
- Flame arrestors
- Manufacturing excellence
- Abuse tolerant and safe
These combined elements deliver increased total energy output, maximized sustained performance, consistent quality, and enhanced durability, designed by Trojan’s world-class engineering team. The Trojan Solar AGM batteries are produced at its U.S.-based manufacturing operations which employs the latest technology, testing and quality check standards in the industry.
|
MODEL NAME
|
CAPACITYA Amp-Hours (Ah) |
ENERGY (kWh) |
DEFAULT TERMINALD |
DIMENSIONSBInches (mm) |
WEIGHTlbs. (kg)E |
HANDLES |
INSTALLATION ORIENTATION |
||||||
|
10-Hr Rate |
20-Hr Rate |
48-Hr Rate |
72-Hr Rate |
100-Hr Rate |
20-Hr Rate |
Length |
Width |
HeightC |
|||||
|
6 VOLT SOLAR DEEP-CYCLE AGM BATTERIES |
|||||||||||||
|
|
190 |
220 |
228 |
231 |
235 |
1.32 |
M8 |
10.30 (262) |
7.06 (179) |
10.73 (273) |
68 (31) |
Embedded |
Horizontal & Vertical |
|
|
278 |
315 |
326 |
331 |
335 |
1.89 |
M8 |
11.66 (296) |
6.94 (176) |
13.99 (355) |
95 (43) |
Braided Rope |
Horizontal & Vertical |
|
|
329 |
375 |
389 |
394 |
400 |
2.25 |
M8 |
11.66 (296) |
6.94 (176) |
16.31 (414) |
114 (52) |
Braided Rope |
Horizontal & Vertical |
|
8 VOLT SOLAR DEEP-CYCLE AGM BATTERIES |
|||||||||||||
|
|
145 |
165 |
168 |
171 |
174 |
1.32 |
M8 |
10.30 (262) |
7.06 (179) |
10.73 (273) |
70 (32) |
Embedded |
Horizontal & Vertical |
|
12 VOLT SOLAR DEEP-CYCLE AGM BATTERIES |
|||||||||||||
|
94 |
105 |
109 |
111 |
113 |
1.26 |
M8 |
12.80 (325) |
6.81 (173) |
9.34 (237) |
67 (30) |
Molded Plastic |
Horizontal & Vertical |
|
|
|
131 |
135 |
136 |
137 |
137 |
1.62 |
M8 |
12.96 (329) |
7.06 (179) |
10.96 (278) |
83 (38) |
Embedded |
Horizontal & Vertical |
|
|
174 |
205 |
210 |
213 |
216 |
2.46 |
M8 |
14.97 (380) |
6.94 (176) |
14.07 (357) |
131 (59) |
Embedded |
Horizontal & Vertical |
| A. | The number of amp-hours(Ah) a battery can deliver when discharged at a constant rate at 86°F (30°C) for all rates and maintain a voltage above 1.75 V/cell. Capacities are based on peak performance. |
| B. | Dimensions may vary depending on type of handle or terminal. Batteries should be mounted with 0.5 inches (12.7mm) spacing minimum. |
| C. | Height taken from bottom of the battery to the highest point on the battery. Heights may vary depending on type of terminal. |
| D. | Terminal images are representative only. |
| E. | Weight may vary. |
Cycle Life Chart for Solar AGM
6V Batteries 8V Batteries 12V Batteries
